- 3484 - QUANTUM GRAVITY - a new window underground? Physicists and civil engineers are advancing another way to use gravity in the form of a “quantum gravimeter” designed to read gravitational fields to “look” deep underground without ever picking up a shovel.
------------ 3484 - QUANTUM GRAVITY - a new window underground?
- The first “quantum, or atomic, gravity gradiometer” capable of taking measurements outside the controlled environment of a mechanics lab exists, in 2022. Gravity sensors which can much more rapidly scan areas, enabling gravity cartography at high resolution, could benefit applications such as infrastructure monitoring, water resource monitoring, and climate sciences.
-
- Using gravity sensors to peer under the Earth’s surface is not a new practice; in fact, it’s been going on for over 20 years. In a nutshell, these devices work using interferometry ,similar to that used to detect gravity waves at LIGO, to compare the paths that atoms take when a laser pulse sends them on two different paths. Comparing the journeys of these atoms can then help scientists understand how local differences in gravitational fields impacted their path.
-
- The sensor is sensitive to differences created by local differences in density or mass, such as pipes or tunnels under the ground, which create a slightly different gravitational pull for the atom as it travels along the trajectories. This allows us to detect things under the ground when we move the sensor.
-
- Atoms that travel through dense dirt will bring back different gravity signals than those that sailed through an open, underground tunnel. Creating a gravity map from this data can help researchers “see” underground.
-
- The sensitivity of these sensors has traditionally been problem because the vibration noise of a nearby car can be indistinguishable from gravitational changes. Einstein’s equivalence principle, which says it's not possible to differentiate between acceleration and gravity.
-
- This means traditional gravity sensors can produce misleading results. That’s where the updated sensor comes into play. Instead of performing this gravity measurement on a handful of atoms, the team’s quantum gravimeter performs these measurements on thousands of atoms that are held in two matching atomic “clouds” within their sensor.
-
- The vibration measured by each cloud is identical. However, because they are a different distance away from a given mass or lack of mass, such as a tunnel, the pull of gravity is different for the two clouds. We then subtract the two readings which removes the unwanted noise due to vibration, but maintains useful gravity information.
-
- Improving the noise reduction of quantum gravimeters can not only help improve the data that scientists receive from such sensors but can also change where these sensors are able to be used as well.
-
- These sensors can be used beyond the lab in outdoor settings which will make the technology much more applicable to fields such as archaeology and civil engineering, which could help save costs as well as potential damage to hidden underground artifacts or utilities.
-
- To test the sea-legs of their sensor, the team wheeled it roughly 55 yards across the street from the university’s mechanical workshop to a quiet Birmingham road with buildings on either side and occasional traffic rumbling by. Three feet beneath this ordinary road sat a roughly 6.5 x 6.5-foot cross-section of a utility tunnel.
-
- With 10 minutes of data collected from this real-world environment, the team was able to construct a gravity map that pinpointed the underground tunnel using data from the sensor alone. While this measurement doesn’t quite match the sensitivity of measurements made in laboratory conditions, it is nonetheless an accomplishment in the portability and practical use of such a sensor.
-
- The techniques developed for this sensor can be used to peer into space as well, such as investigating “dark matter” and ‘gravitational waves‘. This sensing of gravity has emerged as a tool in geophysics applications such as engineering and climate research, including the monitoring of temporal variations in aquifers and geodesy.
-
- It is often impractical to use gravity cartography to resolve meter-scale underground features because of the long measurement times needed for the removal of vibrational noise.
-
- We can overcome this limitation by realizing a practical “quantum gravity gradient sensor“. This new design suppresses the effects of micro-seismic and laser noise, thermal and magnetic field variations, and instrument tilt.
-
- The instrument achieves a statistical uncertainty of 20 “E” where 1 “E” = 10−9 per second^2 , and is used to perform a 0.5-meter-spatial-resolution survey across an 8.5-meter-long line, detecting a 2-meter tunnel with a signal-to-noise ratio of 8.
-
- Using a Bayesian inference method, they can determine the center to ±0.19 meters horizontally and the center depth as 1.89 at −0.59 to +2.3 meters.
-
- The removal of vibrational noise enables improvements in instrument performance to directly translate into reduced measurement time in mapping.
-
- The sensor parameters are compatible with applications in mapping aquifers and evaluating impacts on the water table, archaeology, determination of soil properties and water content, and reducing the risk of unforeseen ground conditions in the construction of critical energy, transport and utilities infrastructure.
-
- Gravity waves are providing a new window into the underground.
-
March 1, 2022 QUANTUM GRAVITY - a new window underground? 3484
----------------------------------------------------------------------------------------
